Interactive Whiteboard

Smart Board

Product Introduction
■ Built-in Android14.0 system and optional with OPS computer module
■ Scan QR code for sharing content, easy-to-use
■ Adopt zero bonding technology
■ Support any signal source annotation function, which can be switched at any time
■ 4K whiteboard infinite display, zoom in/ out of pictures

Specification:

	Model	UMIWB6511	UMIWB7511	UMIWB8611
	Panel Size	65"	75"	86"
Panel	Backlight Type	D-LED
	Resolution	3840 x 2160pixels
	Brightness	350cd/m²(typ.)
	Contrast Ratio	1200 : 1(typ.)
	Pixel Pitch	0.372 (W) x 0.124 (H)
	Frequency	60Hz
	Viewing Angle	178°(H)/178°(V)
	Life Time	50,000hrs(min.)
	Response Time	8ms
	Color Gamut	0.72
	View Area	1428.48 x 803.52 mm	1649.66 x927.936mm	1895.04 x 1065.96mm
Solution	Chipset	GK6760V100
	CPU	Cortex A55*8
	GPU	Quad‐core MaliG52
	Working Frequency	1.2GHz,Max.1.5GHz
	Core	Octa-core
	RAM/ROM	DDR4: 4GB/eMMC:32GB
	OS	Android 14.0
	Bluetooth	5
	WiFi	IEEE802.11a/b/g/n/ac:2.4G+5G
Power	Power Requirements	100~240V，50/60Hz
	Power Consumption Without OPS	≤190W	≤320W	≤410W
	Standby Condition	≤0.5W
	Audio Power	2 x 15W(max)
	OPS Power Supply	DC 18V/≤5A
Structure	Product Size(W x D x H)	1492.784.2900.2 mm	1714.987.41025.4 mm	1961.187.41181.6 mm
	Package Size(W x D x H)	15802051000 mm	18102051150 mm	20602051280 mm
	Housing Material	Aluminum/Metal plate
	Housing Color	Black
	VESA（mm）	500*400 mm	600*400 mm	800*400 mm
	Net Weight	40±2 KG	50±2 KG	68±2 KG
	Gross Weight	51±2 KG	67±2 KG	81±2 KG

*Disclaimer

Due to product configuration and manufacturing process, there may be differences in actual body size/weight. Please refer to the actual product.

The product images in this specification are for illustration only. The actual product effect (including but not limited to appearance, color, size) may vary slightly. Please refer to the actual product.

In order to provide as accurate specification parameters as possible, the text and image effects of this specification may be adjusted and revised in real-time to match the actual product performance, specifications, and other information.

If it is necessary to make the above modifications and adjustments, no special notice will be given.
